Spelsberg 40407001 Junction box, Type of protection IP66/IP67/IP69, max. 4², IK09, Protection class II, Ui 450V AC, Ui 450V DC, DLG, DNV, VDE, Halogen free

€16.40

% €25.23 (35% saved)

Available to order, delivery time: 2-3 Bussines days

Art. No: WST8810234001 P/N: 40407001 Manufacturer: Spelsberg

Secure Payment

Fast Shipping

Expert Advice

Product information "Spelsberg 40407001 Junction box, Type of protection IP66/IP67/IP69, max. 4², IK09, Protection class II, Ui 450V AC, Ui 450V DC, DLG, DNV, VDE, Halogen free"

Spelsberg Junction box, Type of protection IP66/IP67/IP69, max. 4², IK09, Protection class II, Ui 450V AC, Ui 450V DC, DLG, DNV, VDE, Halogen free

Spelsberg 40407001

EAN

Description

Junction box, protection class IP66/IP67/IP69, nominal cross-section 4mm², Ui=450 V AC, certified by VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), DLG (Ammonia resistance), DNV (Class: Ships and Offshore Installations), knockouts, M16/M20/M25, (1 rear, 7 side), internal fixing points, with screwless terminals, for installation in industrial environments and unprotected outdoor areas, black, In=32 A, with 5 floor-fixed, screwless 3-wire terminals, Wago 221-413-4mm², clampable cross-sections per pole: 3 x 0.2 to 4mm² rigid Cu and 3 x 0.14 to 4mm² flexible Cu
Dimensions: 102 x 102 x 70mm
Accessories supplied: 4 double membrane seals IP66 M25 sealing range 9-17mm, cover retainer

Documents & Downloads

Product Attributes

Technical data

P/N (Part Number)	40407001
ETIM	EC002600
Weight	0.23 kg
Weight (Package)	0.23 kg

Designations

Abox Cable junction box DNV Exterior installation IP66 IP67 IP69 Junction box Junction box Junction boxes Junction socket Outdoor applications Screwless Wago 221 abox i abox-i aboxi abx aox boat damp disconnector housing junction box marine maritime screwless terminal ship
