NSYCUHD800DG
Schneider Electric NSYCUHD800DG Outdoor Wall-Mounted Cooling Unit, Climasys CU, 800W, 230V, 50/60Hz, IP55
€1,946.22
Available, delivery time: 2-3 Bussines days
Product number: WST8810036328
Manufacturer: Schneider ElectricP/N: NSYCUHD800DG
Product information "Schneider Electric NSYCUHD800DG Outdoor Wall-Mounted Cooling Unit, Climasys CU, 800W, 230V, 50/60Hz, IP55"
Schneider Electric Outdoor Wall-Mounted Cooling Unit, Climasys CU, 800W, 230V, 50/60Hz, IP55
Schneider Electric NSYCUHD800DG
EAN 3606486055571
Description
Documents & Downloads
Product Attributes
| Ausführung | Luft/Luft |
|---|---|
| Betriebsspannung AC 50 Hz | 220V |
| Betriebsspannung AC 60 Hz | 230V |
| Betriebsspannung DC | -V |
| Spannungsart | AC |
| Drehzahlgeregelt | |
| Mit Temperaturregelung | 1 |
| Funktion Master/Slave | 1 |
| Mit Heizfunktion | |
| Gesamtkühlleistung nach EN 14511 bei 35/35 °C | 875W |
| Luftvolumenstrom Kühlen | 550m³/h |
| Umgebungstemperatur während des Betriebs | -20°C |
| Breite | 345mm |
| Höhe | 780mm |
| Tiefe | 215mm |
Technical data
| P/N (Part Number) | NSYCUHD800DG |
|---|---|
| EAN | 3606486055571 |
| ETIM | EC000855 |
| Weight | 24.4 kg |
| Weight (packaged) | 24.4 kg |
Designations
Cooling Unit Outdoor Cooling Unit Thermal management Thermoelectric cooler Thermoelectric cooling cooling cabinet cooling devices
