1915673
Phoenix Contact 1915673 PCB connector ZEC 1,0/ 4-LPV-3,5 C1
€501.01*
% €657.50* (23.8% saved)Available, delivery time: 2-3 Months
Product number: WST8810192970
Manufacturer: Phoenix ContactP/N: 1915673
Product information "Phoenix Contact 1915673 PCB connector ZEC 1,0/ 4-LPV-3,5 C1"
Phoenix Contact PCB connector ZEC 1,0/ 4-LPV-3,5 C1
Phoenix Contact 1915673
EAN 4017918181505
Description
PCB connector, nominal cross section: 1 mm², color: green, nominal current: 8 A, rated voltage (III/2): 200 V, contact surface: Sn, contact connection type: Socket, number of potentials: 4, number of rows: 1, number of positions: 4, number of connections: 4, product range: ZEC 1,0/..-LPV, pitch: 3.5 mm, mounting: Direct plug-in method, conductor/PCB connection direction: 0 °, number of solder pins per potential: 2, plug-in system: ZEC, locking: without, mounting method: without, type of packaging: packed in cardboard
Documents & Downloads
Product Attributes
| Kontaktausführung | Buchse |
|---|---|
| Polzahl | 4 |
| Anzahl der Steckkontaktreihen | 1 |
| Rastermaß der Kontakte (mm) | 3.5 |
| Rastermaß der Anschlüsse (mm) | 3.5 |
| Bemessungsstrom In (A) | 8 |
| Bemessungsspannung (kV) | 200 |
| Bemessungsstoßspannung (kV) | 2.5 |
| Überspannungskategorie | III |
| Verschmutzungsgrad | 2 |
| Werkstoff der Kontaktbeschichtung | Zinn |
| Ausführung des elektrischen Anschlusses | sonstige |
| Werkstoff des Isolierkörpers | sonstige |
| Gehäusefarbe | grün |
| Brennbarkeitsklasse des Isolierstoffs nach UL94 | V0 |
| Betriebstemperatur (°C) | -40 |
| Befestigungsart | sonstige |
| Art der Banderolierung | Karton (für SMD) |
Technical data
| P/N (Part Number) | 1915673 |
|---|---|
| EAN | 4017918181505 |
| ETIM | EC002637 |
| Weight | 5.96E-5 kg |
| Weight (packaged) | 5.96E-5 kg |
