Dehn 961305 Type 1+2+3 comb. arrester DEHNventil ACI 3-pole f. TN-C sys. w. remote monitoring
€2,072.74
Available, delivery time: 2-3 Weeks
Art. No: WST8810226724 P/N: 961305 Manufacturer: DEHN
Secure Payment
Fast Shipping
Expert Advice
Product information "Dehn 961305 Type 1+2+3 comb. arrester DEHNventil ACI 3-pole f. TN-C sys. w. remote monitoring"
Dehn Type 1+2+3 comb. arrester DEHNventil ACI 3-pole f. TN-C sys. w. remote monitoring
Dehn 961305
EAN
Description
Three-pole, spark-gap-based, Type 1 + Type 2 + Type 3 DEHNventil ACI M TNC combined arrester as per EN 61643-11 with integrated ACI switch/spark gap. Maximum system availability due to RADAX Flow follow current limitation. Capable of protecting terminal equipment. For protecting low-voltage consumer installations against surges and even direct lightning strikes. For use according to the lightning protection zone concept at boundaries 0A – 2.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 961305 |
|---|---|
| ETIM | EC001457 |
| Weight | 2.41 kg |
| Weight (packaged) | 2.85 kg |
Designations
Energietechnik Surge Protection for Power Supply Systems
