952030
Dehn 952030 DEHNgap C S, N-PE surge arrester
€70.11
% €152.56 (54.04% saved)
Available, delivery time: 2-3 Weeks
Product number: WST8810211423
Manufacturer: DEHNP/N: 952030
Product information "Dehn 952030 DEHNgap C S, N-PE surge arrester"
Dehn DEHNgap C S, N-PE surge arrester
Dehn 952030
EAN
Description
Single-pole DEHNgap C S N-PE surge arrester (type 2 according to EN 61643-11) consisting of a base part and plug-in protection module. Specifically designed for use in 3+1 and 1+1 circuits of TT systems according to IEC 60364-5-53 between neutral conductor N and protective conductor PE. For protecting low-voltage consumer´s installations against surges. For installation in conformity with the lightning protection zone concept at the boundaries from 0B – 1 and higher.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 952030 |
|---|---|
| ETIM | EC000941 |
| Weight | 0.111 kg |
| Weight (packaged) | 0.12 kg |
Designations
Energietechnik Surge Protection for Power Supply Systems Type 2 Surge Arresters
