942405
Dehn 942405 Surge arrester type 2+3 DEHNguard MP FM 4-pole Uc 275V for TN-S systems
€122.21
% €503.61 (75.73% saved)
Available, delivery time: 2-3 Weeks
Product number: WST8810210905
Manufacturer: DEHNP/N: 942405
Product information "Dehn 942405 Surge arrester type 2+3 DEHNguard MP FM 4-pole Uc 275V for TN-S systems"
Dehn Surge arrester type 2+3 DEHNguard MP FM 4-pole Uc 275V for TN-S systems
Dehn 942405
EAN
Description
Multipole type-2 + type-3 DEHNguard MP surge arrester, according to EN 61643-11, consisting of a base part and plug-in protection modules and double-push-in connection clamp suitable for stub wiring and feed-through wiring. High device reliability due to Thermo Dynamic Control arrester monitoring. For protecting low-voltage consumer installations against surges. For installation in conformity with the lightning protection zone concept at the boundaries from 0B – 1 and higher.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 942405 |
|---|---|
| ETIM | EC000941 |
| Weight | 0.35091 kg |
| Weight (packaged) | 0.35 kg |
Designations
Energietechnik Surge Protection for Power Supply Systems Type 2 Surge Arresters
