942400
Dehn 942400 Surge arrester type 2+3 DEHNguard MP 4-pole Uc 275V for TN-S systems
€420.67
Available to order, delivery time: 2-3 Bussines days
Art. No: WST8810210903 P/N: 942400 Manufacturer: DEHN
Secure Payment
Fast Shipping
Expert Advice
Product information "Dehn 942400 Surge arrester type 2+3 DEHNguard MP 4-pole Uc 275V for TN-S systems"
Dehn Surge arrester type 2+3 DEHNguard MP 4-pole Uc 275V for TN-S systems
Dehn 942400
EAN
Description
Multipole type-2 + type-3 DEHNguard MP surge arrester, according to EN 61643-11, consisting of a base part and plug-in protection modules and double-push-in connection clamp suitable for stub wiring and feed-through wiring. High device reliability due to Thermo Dynamic Control arrester monitoring. For protecting low-voltage consumer installations against surges. For installation in conformity with the lightning protection zone concept at the boundaries from 0B – 1 and higher.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 942400 |
|---|---|
| ETIM | EC000941 |
| Weight | 0.41 kg |
| Weight (packaged) | 0.41 kg |
Designations
Energietechnik Surge Protection for Power Supply Systems Type 2 Surge Arresters
