942122
Dehn 942122 Type 2 surge arrester DEHNguard MP FM single-phase Uc 385V TT+TN-S Systems
€321.54
Available to order, delivery time: 2-3 Weeks
Art. No: WST8810209557 P/N: 942122 Manufacturer: DEHN
Secure Payment
Fast Shipping
Expert Advice
Product information "Dehn 942122 Type 2 surge arrester DEHNguard MP FM single-phase Uc 385V TT+TN-S Systems"
Dehn Type 2 surge arrester DEHNguard MP FM single-phase Uc 385V TT+TN-S Systems
Dehn 942122
EAN
Description
Multipole type-2 DEHNguard MP ACI surge arrester, according to EN 61643-11, with integrated ACI switch/spark-gap combination, consisting of a base part with plug-in protection modules and double-push-in connection clamp suitable for stub wiring and feed-through wiring. High device reliability due to Thermo Dynamic Control arrester monitoring. For protecting low-voltage consumer installations against surges. For installation in conformity with the lightning protection zone concept at the boundaries from 0B – 1 and higher.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 942122 |
|---|---|
| ETIM | EC000941 |
| Weight | 0.2 kg |
| Weight (packaged) | 0.25 kg |
Designations
Energietechnik Surge Protection for Power Supply Systems Type 2 Surge Arresters
