49040201

Spelsberg 49040201 Junction box, Type of protection IP65, max. 2,5², Impact strength IK08, Protection class II, Ui 690V AC, DLG, DNV, VDE, Halogen free

€ 11,51

% € 15,35 (25.02% bespaard)

Beschikbaar, levertijd: 2-3 Werkdagen

Productnummer: WST8810214074

Manufacturer: Spelsberg
P/N: 49040201

Productinformatie "Spelsberg 49040201 Junction box, Type of protection IP65, max. 2,5², Impact strength IK08, Protection class II, Ui 690V AC, DLG, DNV, VDE, Halogen free"

Spelsberg Junction box, Type of protection IP65, max. 2,5², Impact strength IK08, Protection class II, Ui 690V AC, DLG, DNV, VDE, Halogen free

Spelsberg 49040201

EAN

Beschrijving

Junction box, protection class IP65, nominal cross-section 2.5mm², Ui=690 V AC, certified by VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), DLG (Ammonia resistance), DNV (Class: Ships and Offshore Installations), self-sealing, soft insertion membranes, M20, sealing range 2-16mm, (1 rear, 7 side), internal fixing points, for installations in industrial environments and protected outdoor areas, grey, In=24 A, with screw terminal, 5-pole-2.5mm² (4 x 1.5² / 4 x 2.5²)
Dimensions: 80 x 80 x 52mm

Documenten & Downloads

Productkenmerken

Technische gegevens

P/N (Onderdeelnummer)	49040201
ETIM	EC002600
Gewicht	0.1092 kg
Gewicht (verpakt)	0.11 kg

Benamingen

Abox Cable junction box DNV Damp-proof junction boxes Distribution box Junction box Junction box Junction boxes Junction socket Terminal box abx aox boat cable box cast resin junction box connection box connection box damp disconnector housing distribution box electrical junction box electrical junction box ip65 junction box ip68 junction box junction box junction box junction box junction box 200x200 junction box 80x80 junction box ap junction box ap junction box casting junction box gel junction box ip44 junction box ip65 junction box ip67 junction box surface mounted flat junction box surface mounted wetroom junction box uv resistant junction box watertight gel junction box watertight underground junction boxes marine maritime ship terminal box ip68 watertight junction box watertight junction box
