21120

Schneider Electric 21120 F+SD.O - Signaal-fout contact - 1 M+V - P25M Hulpelementen

€ 26,91

% € 37,01 (27.29% bespaard)

Beschikbaar, levertijd: 7-10 Werkdagen

Productnummer: WST8810005483

Manufacturer: Schneider Electric
P/N: 21120

Productinformatie "Schneider Electric 21120 F+SD.O - Signaal-fout contact - 1 M+V - P25M Hulpelementen"

Schneider Electric F+SD.O - Signaal-fout contact - 1 M+V - P25M Hulpelementen

Schneider Electric 21120

EAN 3303430211204

Beschrijving

Auxiliary contact SD for P25M. 1 normally open and 1 normally closed contact, rated current 2.2A, operating voltage (Ue) 415V AC, width 9mm. Switch position indicator for remote indication of the position of the associated device. Can be mounted on the left side of the device.

Documenten & Downloads

Productkenmerken

Anzahl der Kontakte als Wechsler	1
Anzahl der Kontakte als Schließer	1
Anzahl der Kontakte als Öffner	1
Anzahl der Fehlersignalschalter	0
Bemessungsbetriebsstrom Ie bei AC-15	415A
Ausführung des elektrischen Anschlusses	Schraubanschluss
Ausführung	integrierbar
Montageart	Seitenanbau
Fassung

Technische gegevens

P/N (Onderdeelnummer)	21120
EAN	3303430211204
ETIM	EC000041
SCIP	9da5f8d9-d60f-424a-bb30-a856a097686c
ECLASS	eClass_10_AKN342013
Gewicht	0.044 kg
Gewicht (verpakt)	0.04 kg

Benamingen

Auxiliary block Auxiliary contact block Auxiliary module Auxiliary switch Auxiliary switch block Auxiliary switch element Auxiliary switch module Auxiliary switch module for control devices Auxiliary switch module for front element Base element Built-in device Command and signaling device Contact base Contact block Contact element Control device Double push-button Double push-button with indicator light Instantaneous auxiliary switch Lateral auxiliary switch Push-button Push-button unit Selector switch Signal contact Signal contact/Auxiliary switch Signal switch Signaling device Switching element Switching element for control devices Time-delay auxiliary switch
