Dehn 540801 Pipe clamp f. hazardous areas D 27-89mm w. terminal screw M10 Cu/gal Sn StSt

Pipe clamp for hazardous areas, for electrical contacting of pipes in hazardous areas for implementing lightning equipotential bonding according to DIN EN 62305-3 (VDE 0185-305-3). For use in the potentially explosive areas Ex zones 1 and 2 (gases, vapours, mists) as well as Ex zones 21 and 22 (dusts). Tested to explosion group IIB and to DIN EN 62561-1. Considerable installation time saving – no more need to deactivate systems/areas for welding or drilling work. Design type EX BRS 90, for the clamping range D27-89 mm. Necessary mounting set (part no. 540902) available separately.
