Schneider Electric 18768 Multi9 disjoncteur modulaire - NG125L - 4 pôles - 10 A- courbe B

Acti 9 NG125L circuit breaker, 50kA (IEC/EN 60947-2). 4-pole, nominal current 10A, B-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The triggering is indicated by the central position of the toggle lever and by a red, mechanical indicator on the front of the device. Test button to check the release mechanism. Supply from above or below. Toggle action for low-wear switching of contacts. Technology of the trip unit- thermomagnetic. Auxiliary modules that can be added (optional)- indication of switch position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
