Schneider Electric 18736 Acti9 NG125H - Disjoncteur modulaire 4P 32 A Courbe C 36kA

Circuit breaker Acti 9 NG125H, 36kA (IEC/EN 60947-2). 4-pole, rated current 32A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle and by a red, mechanical indicator on the front of the device. Test button to check the tripping mechanism. Top or bottom feed. Snap-action mechanism for low-wear switching of contacts. Release unit technology- thermomagnetic. Additional auxiliary modules that can be lined up (optional)- display of switch position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125H circuit breaker meets the following standards- IEC/EN 60947-2. Furthermore, this series is VDE certified.
