Schneider Electric 18733 Acti9 NG125H - Disjoncteur modulaire 4P 16 A Courbe C 36kA

Circuit breaker Acti 9 NG125H, 36kA (IEC/EN 60947-2). 3-pole, rated current 16A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the central position of the toggle lever and by a red, mechanical indication on the device front side. Test button to check the tripping mechanism. Supply from top or bottom. Snap action for low-wear switching of contacts. Technology of the tripping unit- thermo-magnetic. Additional modular accessories (optional)- indication of switching position, fault tripping, shunt trip, under-voltage trip, over-voltage trip. The NG125H circuit breaker meets the following standards- IEC/EN 60947-2. Furthermore, this series is VDE certified.
