Schneider Electric 18716 Acti9 NG125H - Disjoncteur modulaire 2P 20 A Courbe C 36kA

Circuit breaker Acti 9 NG125H, 36kA (IEC/EN 60947-2). 1-pole, rated current 10A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Triggering is indicated by the centre position of the toggle lever and by a red, mechanical display on the front of the device. Test button for checking the trigger mechanism. Power supply from above or below. Jump switching for low-wear switching of contacts. Trip unit technology - thermomagnetic. Additional modular accessories (optional) - Indication of switch position, fault tripping, working current release, undervoltage trip, overvoltage trip. The NG125H circuit breaker meets the following standards: IEC/EN 60947-2. Furthermore, this series is VDE certified.
