Schneider Electric 18714 Acti9 NG125H - Disjoncteur modulaire 2P 10 A Courbe C 36kA

Acti 9 NG125H circuit breaker, 36kA (IEC/EN 60947-2). 1-pole, rated current 10A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle and by a red, mechanical indication on the front of the device. Test button to check the tripping mechanism. Power supply from top or bottom. Snap-action mechanism for low-wear switching of contacts. Technology of the tripping unit - thermomagnetic. Additional auxiliary modules can be attached (optional) - indication of switch position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125N circuit breaker meets the following standards: IEC/EN 60947-2. Furthermore, this range is VDE certified.
