Schneider Electric A9N18412 Magnetotérmico, Acti9 C120H, 2P, 63 A, B curva, 15000 A (IEC 60898-1), 15 kA (IEC 60947-2)

Miniature Circuit Breaker Acti 9 iDPN, 6kA (IEC/EN 60898-1), 10kA (IEC/EN 60947-2). Single pole + neutral, rated current 3A, C characteristic, 1 module width, operating voltage (Ue) 400V AC, insulation voltage (Ui) 440V AC. Protection against short circuit and overload in electrical installations where the neutral conductor is switched. The very narrow design allows for high packing density in the distribution board. Trigger unit technology - thermal magnetic. Can be combined with RCD blocks. Additional modular auxiliary units (optional) - indication of switching position, fault trip, shunt trip, under-voltage trip, over-voltage trip. Color RAL 9003. The iDPN circuit breaker meets the following standards: IEC/EN 60898-1 and IEC/EN 60947-2.
