Schneider Electric A9N18402 Magnetotérmico, Acti9 C120H, 1P, 80 A, B curva, 15000 A (IEC 60898-1), 15 kA (IEC 60947-2)

Circuit breaker Acti 9 iC60H, 10kA (IEC/EN 60898-1), 15kA (IEC/EN 60947-2). Double-pole, nominal current 16A, C characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 500V AC. Double connection terminal for cables and comb busbar on the device top and bottom. Jump switching for low-wear switching of the contacts. Accompanying insulation cover. Operation of the DIN rail mounting element on the front of the device for tool-free installation and easy accessibility for the user. With mechanical frontal fault indication (VisiTrip) for displaying trippings caused by overload or short circuit. Safe contact indication (VisiSafe) of the circuit breaker, with a green indicator ensuring the safety of de-energization on the outgoing side. Technology of the triggering unit- thermomagnetic. Can be combined with the RCCBs of the Acti 9 iID series, as well as the RCCB Vigi iC60. Additional modular auxiliaries (optional)- display of switching position, fault tripping, shunt trip, under-voltage trip, over-voltage trip. Color RAL 9003. The iC60H circuit breaker complies with the following standards- IEC/EN 60898-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.
