Schneider Electric 18882 Magnetotérmico, Acti 9 NG125LMA, 3P, 12.5 A, MA curva, 50 kA (IEC 60947-2)

Acti 9 NG125LMA circuit breaker, 50kA (IEC/EN 60947-2). 2-pole, rated current 12.5A, MA characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the middle position of the toggle switch and by a red, mechanical indicator on the front of the device. Test button to check the release mechanism. Feed-in from the top or bottom. Snap action for low-wear switching of contacts. Technology of the release unit- thermomagnetic. Additional auxiliary modules that can be lined up (optional)- indication of switching position, fault tripping, shunt trip, undervoltage release, overvoltage release. The NG125LMA circuit breaker meets the following standards- IEC/EN 60947-2.
