Schneider Electric 18880 Magnetotérmico, Acti 9 NG125LMA, 3P, 6.3 A, MA curva, 50 kA (IEC 60947-2)

Circuit Breaker Acti 9 NG125LMA, 50kA (IEC/EN 60947-2). 2-pole, rated current 6.3A, MA characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the mid-position of the toggle and by a red, mechanical indication on the front of the device. Test button to check the trigger mechanism. Power supply from top or bottom. Jumping mechanism for low-wear switching of the contacts. Technology of the trigger unit- thermomagnetic. Additional auxiliary modules can be added (optional)- indication of switch position, fault tripping, working current trip, under voltage trip, over voltage trip. The NG125LMA circuit breaker meets the following standards: IEC/EN 60947-2.
