Schneider Electric 18874 Magnetotérmico, Acti 9 NG125LMA, 2P, 40 A, MA curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 4-pole, rated current 50A, D characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle switch and a red, mechanical indicator on the front of the device. Test button for checking the tripping mechanism. Supply from above or below. Snap-action mechanism for low-wear switching of the contacts. Trip unit technology- thermomagnetic. Additionally modular add-ons (optional)- indication of switching position, fault tripping, shunt trip, under-voltage release, over-voltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
