Schneider Electric 18862 Magnetotérmico, Acti9 NG125L, 4P, 40 A, D curva, 50 kA (IEC 60947-2)

Acti 9 NG125L circuit breaker, 50kA (IEC/EN 60947-2). 4-pole, rated current 40A, D characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the central position of the toggle and by a red, mechanical indicator on the front of the device. Test button to check the tripping mechanism. Supply from the top or bottom. Snap action for low-wear switching of the contacts. Tripping unit technology- thermomagnetic. Additional auxiliary modules can be added (optional)- indication of switching position, fault tripping, shunt trip, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
