Schneider Electric 18858 Magnetotérmico, Acti9 NG125L, 4P, 16 A, D curva, 50 kA (IEC 60947-2)

Acti 9 NG125L circuit breaker, 50kA (IEC/EN 60947-2). 4-pole, rated current 16A, D characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Circuit protection against short-circuit currents. Circuit protection against overload currents. Tripping is indicated by the mid-position of the switch lever and by a red, mechanical indicator on the front of the device. Test button to check the tripping mechanism. Feeding from top or bottom. Snap-action mechanism for low-wear switching of contacts. Trip unit technology - thermomagnetic. Additional auxiliary modules that can be attached (optional) - indication of switch position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
