Schneider Electric 18827 Magnetotérmico, Acti9 NG125L, 4P, 50 A, C curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 4-pole, nominal current 50A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the central position of the toggle lever and by a red, mechanical display on the front of the device. Test button for checking the tripping mechanism. Supply from top or bottom. Snap-action mechanism for low-wear switching of contacts. Technology of the trigger unit- thermomagnetic. Additional adjoining auxiliary modules (optional)- indication of switching position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards- IEC/EN 60947-2.
