Schneider Electric 18812 Magnetotérmico, Acti9 NG125L, 4P, 20 A, C curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 3-pole, rated current 20A, C characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the central position of the toggle lever and by a red, mechanical indicator on the front of the device. Test button for checking the tripping mechanism. Supply can be top or bottom. Snap-action mechanism for low-wear switching of contacts. Technology of the tripping unit- thermomagnetic. Additional modular auxiliary components (optional)- indication of switch position, fault trip, working current trip, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards- IEC/EN 60947-2.
