Schneider Electric 18799 Magnetotérmico, Acti9 NG125L, 3P, 10 A, C curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 3-pole, rated current 10A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The trip is indicated by the middle position of the toggle and by a red mechanical indicator on the front of the device. Test button for checking the tripping mechanism. Feed-in from top or bottom. Positive break contact system for low-wear switching of the contacts. Technology of the trip unit- thermomagnetic. Additional auxiliary modules that can be snapped on (optional)- indication of switch position, fault tripping, working current trip, undervoltage trip, overvoltage trip. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
