Schneider Electric 18796 Magnetotérmico, Acti9 NG125L, 2P, 80 A, C curva, 50 kA (IEC 60947-2)

Power circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). Single pole, rated current 80A, C curve characteristics, operating voltage (Ue) 220-240V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle lever and by a red, mechanical indication on the front of the device. Test button for checking the trigger mechanism. Top or bottom feed. Snap-action mechanism for low-wear switching of contacts. Unit tripping technology - thermomagnetic. Additional auxiliary modules that can be lined up (optional) - Indication of switching state, fault tripping, working current trip, undervoltage trip, overvoltage trip. The NG125L circuit breaker meets the following standards - IEC/EN 60947-2.
