Schneider Electric 18776 Magnetotérmico, Acti9 NG125L, 4P, 80 A, B curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 3-pole, nominal current 80A, B-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The trip is indicated by the mid position of the control lever and by a red, mechanical display on the front of the device. Test button to check the trigger mechanism. Supply from above or below. Snap-action for low-wear switching of contacts. Technology of the trigger unit- thermomagnetic. Additional modular auxiliary units (optional)- indication of switching position, fault tripping, work current tripper, under-voltage tripper, over-voltage tripper. The NG125L circuit breaker meets the following standards- IEC/EN 60947-2.
