Schneider Electric 18772 Magnetotérmico, Acti9 NG125L, 4P, 32 A, B curva, 50 kA (IEC 60947-2)

Circuit Breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 3-pole, rated current 32A, B curve, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle and by a red, mechanical indication on the front of the device. Test button to check the release mechanism. Top or bottom feeding. Spring mechanism for low-wear switching of the contacts. Triggering unit technology - thermomagnetic. Additionally connectable auxiliary modules (optional) - indication of switch position, fault tripping, shunt trip, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
