Schneider Electric 18762 Magnetotérmico, Acti9 NG125L, 3P, 25 A, B curva, 50 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125L, 50kA (IEC/EN 60947-2). 3-phase, rated current 25A, B-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle lever and by a red mechanical display on the front of the device. Test button to check the tripping mechanism. Top or bottom feeding. Snap action for low-wear switching of contacts. Technology of the tripping unit- thermomagnetic. Additional auxiliary modules that can be lined up (optional)- display of switching position, fault tripping, work current release, undervoltage release, overvoltage release. The NG125L circuit breaker meets the following standards: IEC/EN 60947-2.
