Schneider Electric 18718 Magnetotérmico, Acti9 NG125H, 2P, 32 A, C curva, 36 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125H, 36kA (IEC/EN 60947-2). 1-pole, nominal current 32A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the central position of the toggle and by a red, mechanical display on the front of the device. Test button to check the trip mechanism. Supply can be from above or below. Rocking mechanism for low-wear switching of contacts. Technology of the trip unit- thermomagnetic. Additional auxiliary modules can be attached (optional)- indication of switch position, fault trip, shunt trip, under voltage release, over voltage release. The NG125H circuit breaker complies with the following standards- IEC/EN 60947-2. Furthermore, this series is VDE certified.
