Schneider Electric 18707 Magnetotérmico, Acti9 NG125H, 1P, 20 A, C curva, 36 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125N, 25kA (IEC/EN 60947-2). 4-pole, rated current 125A, B characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the middle position of the toggle and by a red mechanical indicator on the front of the device. Test button for checking the release mechanism. Supply possible from top or bottom. Snap-action mechanism for low-wear switching. Release unit technology - thermomagnetic. Additional modular auxiliaries (optional) - indication of switch position, fault tripping, shunt trip, undervoltage release, overvoltage release. The NG125N circuit breaker meets the following standards: IEC/EN 60947-2. Furthermore, this series is VDE certified.
