Schneider Electric 18647 Miniature circuit-breaker, Acti9 NG125N, 3P+N, 100 A, C curve, 25 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125N, 25kA (IEC/EN 60947-2). 3-pole, rated current 25A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The tripping is indicated by the middle position of the toggle and by a red, mechanical indicator on the front of the device. Test button for checking the tripping mechanism. Top or bottom feeding. Bounce-free switchgear for wear-resistant switching of the contacts. Technology of the trigger unit - thermomagnetic. Additionally lined up auxiliary modules (optional) - Indication of switching status, fault tripping, working current release, under-voltage release, over-voltage release. The NG125N circuit breaker complies with the following standards: IEC/EN 60947-2. Furthermore, this series is VDE certified.
