C25F4TM160

Schneider Electric C25F4TM160 Interruttore, ComPacT NSX250F, 36kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 160A

1.588,99 €

Ordinabile ora, tempo di consegna: 2-3 Settimane

Art. No: WST8810013487 P/N: C25F4TM160 Produttore: Schneider Electric

Pagamento sicuro

Spedizione rapida

Consulenza specializzata

Info sui prodotti "Schneider Electric C25F4TM160 Interruttore, ComPacT NSX250F, 36kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 160A"

Schneider Electric Interruttore, ComPacT NSX250F, 36kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 160A

Schneider Electric C25F4TM160

EAN 3606481997586

Apri la visualizzazione a schermo intero a 360°

Descrizione

This ComPacT NSX250F is a complete 4P 4d circuit breaker in a fixed configuration, designed to optimize space and breaking capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 36 kA rms at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC, 50/60 Hz. This product features a thermal-magnetic trip unit (TMD) with a rated power of 160 A. The TMD trip unit offers adjustable thermal overload protection and a fixed magnetic protection. This 4-pole design (140 mm x 161 mm x 86 mm) comes with a variety of optional features and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. The ComPacT NSX250F is part of Schneider Electric's EcoStruxure Power architecture.

Documenti e download

Attributi del prodotto

Bemessungsdauerstrom Iu	160A
Bemessungsspannung	690V
Bemessungsgrenzkurzschlussausschaltstrom Icu bei 400 V	36kA
Überlastauslöser Stromeinstellung	175A
Einstellbereich des kurzzeitverzögerten Kurzschlussauslösers	-A
Einstellbereich des unverzögerten Kurzschlussauslösers	1250A
Verlustleistung	47.12W
Gerätebauart	Einbaugerät Festeinbautechnik
Integrierter Erdschlussschutz
Anschlussart Hauptstromkreis	Schraubanschluss
Geeignet für Hutschienenmontage
Hutschienenmontage optional	1
Anzahl der Hilfskontakte als Öffner	0
Anzahl der Hilfskontakte als Schließer	0
Anzahl der Hilfskontakte als Wechsler	0
Mit Ausgelöstmelder	1
Mit integriertem Unterspannungsauslöser
Polzahl	4
Position des Anschlusses für Hauptstromkreis	vorne
Ausführung des Betätigungselements	Knebel
Komplettgerät mit Schutzeinheit	1
Motorantrieb integriert
Motorantrieb optional	1
Schutzart (IP)	IP40

Dati tecnici

P/N (Codice articolo)	C25F4TM160
EAN	3606481997586
ETIM	EC000228
SCIP	3874e08b-fcb8-4aa9-87c4-d36abebf2833
ECLASS	eClass_10_AJZ716013
Peso	2 kg
Peso (pacco)	2.56 kg

Designazioni

160 A 4 poles 415 VAC C25F4TM160 ComPacT NSX TMD circuit breaker
