Schneider Electric C25B4 Base interruttore, ComPacT NSX250B, 25kA/415VAC, 4 poli, valore nominale telaio 250A, senza Sganciatore

This is a basic switch with 4 poles for ComPacT NSX250B. ComPacT NSX is designed to optimize space and switching capacity for all standard and special applications. This basic switch is delivered without a trip unit and is compatible with all types of trip units, which must be ordered separately. The ultimate breaking capacity Icu is 25 kA at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz (limited to 440 VAC 50/60 Hz if residual current protection is present). It can be equipped with a variety of optional functions and accessories. The dimensions are 140 mm x 161 mm x 86 mm. It ensures compliance with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX250B is part of the EcoStruxure Power architecture by Schneider Electric.
