C16N3TM125

Schneider Electric C16N3TM125 Interruttore, ComPacT NSX160N, 50kA/415VAC, 3 poli, Sganciatore TMD 125A

849,41 €

Ordinabile ora, tempo di consegna: 7-10 Giorni lavorativi

Art. No: WST8810013373 P/N: C16N3TM125 Produttore: Schneider Electric

Pagamento sicuro

Spedizione rapida

Consulenza specializzata

Info sui prodotti "Schneider Electric C16N3TM125 Interruttore, ComPacT NSX160N, 50kA/415VAC, 3 poli, Sganciatore TMD 125A"

Schneider Electric Interruttore, ComPacT NSX160N, 50kA/415VAC, 3 poli, Sganciatore TMD 125A

Schneider Electric C16N3TM125

EAN 3606481997814

Apri la visualizzazione a schermo intero a 360°

Descrizione

This ComPacT NSX160N is a complete 3P 3D molded case circuit breaker designed to optimize space requirements and disconnecting capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 50 kA rms at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product comes with a thermal-magnetic trip unit (TMD) with a rated current of 125 A. The TMD trip unit offers an adjustable thermal overload protection and a fixed magnetic protection. This 3-pole model (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX160N is part of Schneider Electric's EcoStruxure Power architecture.

Documenti e download

Attributi del prodotto

Bemessungsdauerstrom Iu	125A
Bemessungsspannung	690V
Bemessungsgrenzkurzschlussausschaltstrom Icu bei 400 V	50kA
Überlastauslöser Stromeinstellung	88A
Einstellbereich des kurzzeitverzögerten Kurzschlussauslösers	-A
Einstellbereich des unverzögerten Kurzschlussauslösers	1250A
Verlustleistung	32.34W
Gerätebauart	Einbaugerät Festeinbautechnik
Integrierter Erdschlussschutz
Anschlussart Hauptstromkreis	Schraubanschluss
Geeignet für Hutschienenmontage
Hutschienenmontage optional	1
Anzahl der Hilfskontakte als Öffner	0
Anzahl der Hilfskontakte als Schließer	0
Anzahl der Hilfskontakte als Wechsler	0
Mit Ausgelöstmelder	1
Mit integriertem Unterspannungsauslöser
Polzahl	3
Position des Anschlusses für Hauptstromkreis	vorne
Ausführung des Betätigungselements	Knebel
Komplettgerät mit Schutzeinheit	1
Motorantrieb integriert
Motorantrieb optional	1
Schutzart (IP)	IP40

Dati tecnici

P/N (Codice articolo)	C16N3TM125
EAN	3606481997814
ETIM	EC000228
SCIP	3874e08b-fcb8-4aa9-87c4-d36abebf2833
ECLASS	eClass_10_AJZ716013
Peso	1.78 kg
Peso (pacco)	1.84 kg

Designazioni

125 A 3 Pole 415 VAC C16N3TM125 Circuit Breaker Compact NSX TMD
