Schneider Electric C10W35E100 Interruttore, ComPacT NSX100HB2, 100kA/690VAC, 3 poli, Sganciatore MicroLogic 5.2E 100A

This ComPacT NSX100HB2 is a complete 3P 3D circuit breaker in fixed construction, designed to optimize space requirements and breaking capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 100 kA rms at 500 VAC 50/60 Hz and 100 kA rms at 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product features an electronic trip unit MicroLogic 5.2 E with a rated current of 100 A. The MicroLogic 5.2 E trip unit offers adjustable long-time, short-time, and instantaneous protection. MicroLogic 5.2 E includes an integrated display for fine-tuning and displaying the energy counter. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional features and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX100HB2 is part of Schneider Electric's EcoStruxure Power architecture.
