Schneider Electric C10V46E100 Interruttore, ComPacT NSX100HB1, 75kA/690VAC, 4 poli, Sganciatore MicroLogic 6.2E 100A

This ComPacT NSX100HB1 is a complete 4P 4D circuit breaker in a fixed mount, designed for space optimization and switching capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 85 kA RMS at 500 VAC 50/60 Hz and 75 kA RMS at 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product features an electronic trip unit MicroLogic 6.2 E with a rated power of 100 A and an adjustable ground fault protection (OFF position). The MicroLogic 6.2 E tripping unit offers adjustable long-term, short-term, and instantaneous protection. MicroLogic 6.2 E features an integrated display for fine-tuning and displaying the energy meter. This 4-pole version (140 mm x 161 mm x 86 mm) is delivered with a variety of optional features and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. The ComPacT NSX100HB1 is part of Schneider Electric's EcoStruxure Power architecture.
