Schneider Electric C10V3TM100 Interruttore, ComPacT NSX100HB1, 75kA/690VAC, 3 poli, Sganciatore TMD 100A

This ComPacT NSX100HB1 is a complete 3P 3D fixed circuit breaker designed for optimizing space requirements and breaking capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 85 kA RMS at 500 VAC 50/60 Hz and 75 kA RMS at 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product features a thermal-magnetic trip unit (TMD) with a nominal rating of 100 A. The TMD trip unit offers adjustable thermal overload protection and a fixed magnetic protection. This 3-pole version (105 mm x 161 mm x 86 mm) is supplied with a variety of optional features and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX100HB1 is part of the EcoStruxure Power architecture of Schneider Electric.
