C10N4TM063

Schneider Electric C10N4TM063 Interruttore, ComPacT NSX100N, 50kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A

621,43 €

Ordinabile ora, tempo di consegna: 7-10 Giorni lavorativi

Art. No: WST8810012750 P/N: C10N4TM063 Produttore: Schneider Electric

Pagamento sicuro

Spedizione rapida

Consulenza specializzata

Info sui prodotti "Schneider Electric C10N4TM063 Interruttore, ComPacT NSX100N, 50kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A"

Schneider Electric Interruttore, ComPacT NSX100N, 50kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A

Schneider Electric C10N4TM063

EAN 3606481998156

Apri la visualizzazione a schermo intero a 360°

Descrizione

ComPacT NSX100N to kompletny wyłącznik 4-biegunowy 4d zaprojektowany z myślą o optymalizacji zajmowanego miejsca i zdolności wyłączania. Jest optymalnym wyborem dla wszystkich standardowych i określonych zastosowań. Zdolność zwarciowa (Icu) wynosi 50 kA rms przy 415VAC 50/60Hz. Znamionowe napięcie łączeniowe wynosi 690VAC 50/60Hz. Produkt ten posiada termiczno-magnetyczną jednostkę wyzwalacza (TMD) o wartości 63A. Jednostka wyzwalacza TMD zapewnia regulowane zabezpieczenie termiczne przed przecią żeniem i stałe zabezpieczenie magnetyczne. Wersja 4-biegunowa (140mm x 161mm x 86mm) jest wyposażona w wiele opcjonalnych funkcji i akcesoriów. Jest zgodna z międzynarodowymi normami (IEC 60947), CCC, EAC i specyfikacjami morskimi. ComPacT NSX100N j est częścią architektury Schneider Electric EcoStruxure Power. Green Premium pozwoli spełnić Twoje zobowiązania w zakresie zrównoważonego rozwoju, zapewniając produktom zgodność z przepisami dotyczącymi ochrony środowiska, takimi jak RoHS i REACH, a także doskonałą przejrzystość w kwestii ujawniania informacji o środowisku i instrukcji dotyczących zakończenia eksploatacji.

Documenti e download

Attributi del prodotto

Bemessungsdauerstrom Iu	63A
Bemessungsspannung	690V
Bemessungsgrenzkurzschlussausschaltstrom Icu bei 400 V	50kA
Überlastauslöser Stromeinstellung	44A
Einstellbereich des kurzzeitverzögerten Kurzschlussauslösers	-A
Einstellbereich des unverzögerten Kurzschlussauslösers	500A
Verlustleistung	34.44W
Gerätebauart	Einbaugerät Festeinbautechnik
Integrierter Erdschlussschutz
Anschlussart Hauptstromkreis	Schraubanschluss
Geeignet für Hutschienenmontage
Hutschienenmontage optional	1
Anzahl der Hilfskontakte als Öffner	0
Anzahl der Hilfskontakte als Schließer	0
Anzahl der Hilfskontakte als Wechsler	0
Mit Ausgelöstmelder	1
Mit integriertem Unterspannungsauslöser
Polzahl	4
Position des Anschlusses für Hauptstromkreis	vorne
Ausführung des Betätigungselements	Knebel
Komplettgerät mit Schutzeinheit	1
Motorantrieb integriert
Motorantrieb optional	1
Schutzart (IP)	IP40

Dati tecnici

P/N (Codice articolo)	C10N4TM063
EAN	3606481998156
ETIM	EC000228
SCIP	3874e08b-fcb8-4aa9-87c4-d36abebf2833
ECLASS	eClass_10_AJZ716013
Peso	2.29 kg
Peso (pacco)	2.32 kg

Designazioni

4 poles 415 VAC 63 A C10N4TM063 Circuit breaker Compact NSX TMD
