C10H4TM063

Schneider Electric C10H4TM063 Interruttore, ComPacT NSX100H, 70kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A

672,55 €

Ordinabile ora, tempo di consegna: 2-3 Settimane

Art. No: WST8810012713 P/N: C10H4TM063 Produttore: Schneider Electric

Pagamento sicuro

Spedizione rapida

Consulenza specializzata

Info sui prodotti "Schneider Electric C10H4TM063 Interruttore, ComPacT NSX100H, 70kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A"

Schneider Electric Interruttore, ComPacT NSX100H, 70kA/415VAC, 4 poli 4D (neutro totalmente protetto), Sganciatore TMD 63A

Schneider Electric C10H4TM063

EAN 3606481998941

Apri la visualizzazione a schermo intero a 360°

Descrizione

This ComPacT NSX100H is a complete 4P 4D fixed-mount circuit breaker designed to optimize space and switching capacity. It is an optimal choice for all standard and specialized applications. The breaking capacity (Icu) is 70 kA eff. at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product comes with a thermal-magnetic trip unit (TMD) rated at 63 A. The TMD offers an adjustable thermal overload protection and a fixed magnetic protection. This 4-pole version (140 mm x 161 mm x 86 mm) is delivered with a variety of optional features and accessories. It meets international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX100H is part of the EcoStruxure Power architecture by Schneider Electric.

Documenti e download

Attributi del prodotto

Bemessungsdauerstrom Iu	63A
Bemessungsspannung	690V
Bemessungsgrenzkurzschlussausschaltstrom Icu bei 400 V	70kA
Überlastauslöser Stromeinstellung	70A
Einstellbereich des kurzzeitverzögerten Kurzschlussauslösers	-A
Einstellbereich des unverzögerten Kurzschlussauslösers	500A
Verlustleistung	34.44W
Gerätebauart	Einbaugerät Festeinbautechnik
Integrierter Erdschlussschutz
Anschlussart Hauptstromkreis	Schraubanschluss
Geeignet für Hutschienenmontage
Hutschienenmontage optional	1
Anzahl der Hilfskontakte als Öffner	0
Anzahl der Hilfskontakte als Schließer	0
Anzahl der Hilfskontakte als Wechsler	0
Mit Ausgelöstmelder	1
Mit integriertem Unterspannungsauslöser
Polzahl	4
Position des Anschlusses für Hauptstromkreis	vorne
Ausführung des Betätigungselements	Knebel
Komplettgerät mit Schutzeinheit	1
Motorantrieb integriert
Motorantrieb optional	1
Schutzart (IP)	IP40

Dati tecnici

P/N (Codice articolo)	C10H4TM063
EAN	3606481998941
ETIM	EC000228
SCIP	3874e08b-fcb8-4aa9-87c4-d36abebf2833
ECLASS	eClass_10_AJZ716013
Peso	2.29 kg
Peso (pacco)	2.79 kg

Designazioni

4 Pole 415 VAC 63 A C10H4TM063 Circuit breaker Compact NSX TMD
