Schneider Electric 18661 Magnetotérmico, Acti9 NG125N, 4P, 125 A, C curva, 25 kA (IEC 60947-2)

Circuit breaker Acti 9 NG125N, 25kA (IEC/EN 60947-2). 4-pole, rated current 25A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protection of the circuit against short-circuit currents. Protection of the circuit against overload currents. The triggering is indicated by the center position of the switching knob and by a red, mechanical indication on the front of the device. Test button to check the tripping mechanism. Supply can be from the top or bottom. Snap action for low-wear switching of contacts. Technology of the trigger unit - thermomagnetic. Additional modular accessories (optional) - indication of switch position, fault tripping, working current release, undervoltage release, overvoltage release. The NG125N circuit breaker meets the following standards: IEC/EN 60947-2. Furthermore, this series is VDE certified.
